1.function of metal fifilm dislocation and cutting offff, the protection of inner supporting light fifilm, the optional cleaning of metal fifilm, the avoidance of dust, the saving of metal fifilm and the improvement of product performance.
2. The material reel is inserted on the same side of the same conduit, which effffectively improves the coaxiality of the two semi-axes and the winding accuracy.
3. It has the function of automatic tightening and automatic pre-pressing of key-type fifilm material.
4. It has the function of automatic elimination and classifification of the fifirst defective products.
5. This machine adopts PLC + touch screen control, with capacity, tension, pressure calculation, storage and reading functions.
6. The pressure of the main wheel is controlled by pneumatic double pressure wheel; the pressure of the wheel is adjustable; and the pressure is controlled by electric proportional valve.
7. The whole machine is controlled by Panasonic AC servo system, and the winding tension is controlled by Japanese precision low friction cylinder, which can improve the accuracy and compensate the tension when the speed is lowered.
8. Metallized fifilm material axis unwinding has translation follow-up flflattening roller mechanism to effffectively prevent fifilm material wrinkling; material tray movement adopts double-column guidance to improve movement accuracy.
9. The speed of inner and outer package, outer seal and inner seal can be adjusted.
10. It has the function of secondary heat seal. The time and pressure of primary heat seal and secondary heat seal can be set separately, which is convenient for the later process.
11. It has the function of displaying the I/O signal status of the PLC; the fault alarm has the visual display of the fault guidance solution.
12. Pre-adjustment of automatic stagger position and accuracy maintenace funciton of optional film mateial.
